Description
The Ford Diagnostic & Repair System (FDRS) is Ford’s official, next-generation dealership-level diagnostic software for Ford and Lincoln vehicles. This course provides an in-depth look at the FDRS scan tool, teaching technicians how to navigate the software, understand Ford diagnostic strategies, interpret diagnostic trouble codes (DTCs), and perform advanced diagnostic and bidirectional testing. Through practical demonstrations and real-world applications, technicians will gain the knowledge needed to diagnose and repair Ford vehicles accurately and efficiently.
Topics Covered:
- Ford diagnostic strategies
- Ford DTC structure
- FDRS scan tool navigation
- Module identification and communication
- Power balance testing
- Fuel pressure testing
- Bidirectional controls
- Active tests and functional tests
- Ford diagnostic workflows
Objectives:
- Explain Ford diagnostic strategies
- Interpret Ford DTC structures
- Navigate the FDRS scan tool efficiently
- Perform power balance testing using FDRS
- Conduct fuel pressure testing with FDRS
- Utilize bidirectional controls to verify system operation
- Apply FDRS diagnostic procedures to accurately identify vehicle faults
Runtime = 101 minutes
Credit Hours = 2.00
