Description
Gain the skills to safely diagnose and service hybrid vehicle systems. Learn to identify high-voltage components, disable the high-voltage system, and perform diagnostics on integrated hybrid modules. Analyze battery cell voltages, understand BECM inputs, and master high-voltage contactor operation for safe, effective repairs. Ideal for technicians seeking advanced hybrid vehicle expertise.
Topics Covered:
- High Voltage Safety
- Ford FDRS Scan Tool
- Engine Design
- Integrated Hybrid Module Operation
- Drive Modes
- High Voltage Battery and High Voltage Contactors
Course Objectives:
- Select proper high voltage safety equipment
- Identify high voltage components
- Perform tests on three-phase motors
- Learn how to disable high voltage systems
- Perform diagnostics on the integrated hybrid module
- Perform high voltage cooling system procedures.
Runtime: 55 minutes
Credit Hours: 1.50
