Labscope Diagnostics Version 3.0

AVI instructor Bill Fulton updates his labscope diagnostic strategies with new case studies focusing on compression waveforms.

Even those technicians who have been using their labscopes for years will acquire new tips and techniques for quicker and more accurate engine diagnostics.

Course Objectives:

• Compression & Vacuum Testing Using Waveform Analysis
• Using Exhaust Pulse Waveforms For Misfire Analysis
• Checking Mechanical Integrity Using Cranking Vacuum Waveforms
• Compression Waveform Analysis Using Pressure Transducers
• Fuel Injector Pressure Waveform Analysis
• Fixed & Variable Valve Timing Checks Using Amperage Waveform Analysis
• Crankcase Pressure & Vacuum Testing Techniques Using Waveform Analysis
• Jeep & Ford Hands-On Testing Using Waveform Testing

Runtime: 48.5 minutes
